HPC in the Cloud

Building an AWS environment for quantum-device simulation

Author

Cameron Rutherford

Published

June 15, 2026

Who I Am

I worked at Amazon supporting the Center for Quantum Computing (CQC).

Split Keyboard == True Programmer

Amazon CQC

Ocelot Chip

Designing Superconducting Qubit Chips

s

Palace

Palace, for PArallel LArge-scale Computational Electromagnetics, is an open-source, parallel finite element code for full-wave 3D electromagnetic simulations in the frequency or time domain, using the MFEM finite element discretization library and libCEED library for efficient exascale discretizations.

Palace (Meshing)

Single Transmon Mesh

Palace (Simulation)

Single Transmon Simulation

Intro

How do we design an HPC environment on AWS for quantum-device simulation?

Requirements:

  1. On-demand compute for bursty workloads
  1. HPC Scheduler / Queue for Palace simulations and other workflows
  1. Interactive desktops for analysis and visualization
  1. Secure and reliable environment for real research

Burtsy Workloads

A key constraint was that workloads were bursty.

Researchers often needed:

  • Large instances on short notice (100+ c7gn nodes per simulation)
  • Interactive desktops for analysis and visualization
  • GPU capacity for visualization and related work
  • Shared software environments for HPC and desktop work

Always on nodes would have been too expensive, and the demand was not predictable enough to rely on reserved capacity.

SOCA Architecture

Outdated / Slightly Inaccurate

SOCA Improvements

Generally five categories of improvements were needed:

  • Better AMI (Amazon Machine Images) images and build process
  • Architectural improvements through updating the codebase
  • Security and authentication improvements
  • AI / workflow improvements
  • Palace / Spack improvements

AMIs Improvements

  1. Improve the process for building AMIs
  • AMI builder scripts didn’t have set -x, so I added that for better debugging
  • Some gnuutils libraries are blocked in us-east-1, so we had to move to building AMIs in us-east-2, and copying them to to other regions
  1. Add new features to the AMIs
  • GPU support was added, requiring navigation of NVDIA drivers
  • Updating things like gcc and other packages to support newer instance types
  1. Improve load times and UX for AMIs
  • x86/arm64, GRID / TESLA, desktop / compute nodes (5 total AMIs)
  • To speed up load times, needed to modify SOCA code to prevent runtime installation of some packages and to support custom AMIs

Architectural Improvements

  1. Deprecate our old AL2 deployment
  • Moving from AL2 to Ubuntu 22.04 for better VSCode support (glibc et al.)
  • Port OpenLDAP from one scheduler to another, which was non-trivial
  1. Upgrade from SOCA-lite to newest version of code (3+ year gap)
  • Moving to EC2 Fleet from EC2 ASG for better spot capacity management
  • Windows desktop support for windows specific software for some users
  • ODCR for improved UX when Insufficient Capacity Error (ICE) occurs
  1. Additional improvements to the infrastructure
  • Queue default limits to reduce impact of problem users, improve reliability
  • Increased capacity + OSTs to reduce IOPs contention, capacity alerts

Security and Auth Improvements

  1. Move from OpenLDAP to AWS Managed Active Directory (MAD), adding SSO
  • MAD removed single point of failure, easing transitions between deployments
  • SSO removes passwords for auth. Implemented ALB in Typescript + patches
  1. Improvements around SOCA and AWS MAD integration
  • Clearing desktops from AD when terminated to prevent duplicate objects
  • JSON based AD infromation to remove the need for compute nodes to AD join
  1. More linux related security improvements
  • Adding rootless container runtimes / profiling to SOCA, allowing for POLP
  • Improving filesystem permissions to use linux groups, not r-x everywhere

AI / Workflow Improvementss

  1. Virtual Desktop UX improvement / VSCode + Tmux
  • Gnome desktop support, as well as network improvements to reduce latency
  • Tmux + VSCode for persistent terminals when doing agentic / julia work
  1. AI related workflow improvements
  • SOCA AI plugin to reduce user pain points, giving context to documentation
  • CCMT MCP, and reverse engineering for programmatic capacity queries
  1. Traditional HPC workflow improvements
  • For loops within jobs (flux), instead of for loops submitting jobs
  • /scratch for Palace and other workflows (Python/Julia slow on Lustre)

Spack / Palace Improvements

  1. Spackifying Palace
  • Transition from CMake super-build to modular and spack based
  • GHCR cache in CI to reduce builds form 1hr 15min to 15min!
  • ECR as OCI storage prototyping with Spack developers
  1. Palace on EKS? Viable alternative but not spot-compute…
  • Spack OCI builds allowed container generation in GitHub CI
  • Paladin for cross-region workflows using REST API + EKS backends
  1. Profiling, Performance, and Memory
  • OOM tripwire for better UX when running simulations that are “too large”
  • Transition from shared to dedicated instances due to “noisy neighbour” issue

Lessons Learned

The biggest lesson was that infrastructure is not just about machines. It is about enabling a scientific workflow, and making user’s lives easier.

That means paying attention to:

  • What the current limitations are, and how they impact users
  • Security and reliability concerns
  • The overall research workflow, and how infrastructure can support it

Questions?

Thank you for listening!
